    LDPE BOPP Film Recycling and Washing Line
    PE PP Film and Bag Washing Line(Standard Configuration) Description: Brief Introduction: QINGCHENYU Company is a professional manufacturer for design and production of waste Film washing recycling linewaste bottle washing recycling line wh
    Share to:
    • Technical Specification
    • Video



    PE PP Film and Bag Washing Line(Standard Configuration) Description:

    Brief Introduction: QINGCHENYU Company is a professional manufacturer for design and production of waste Film washing recycling line&waste bottle washing recycling line, which is mainly used to recycle waste plastic PE PP waste bottles, PE PP waste films and PE PP woven bags, jumbo bags, Ton bags&Bulk bags.


    PE Film recycling line mainly includes belt conveyor, metal detector, single double shaft shredder, film crusher with water, floating tank, hot washer,high speed friction washer, special film squeezer or film densifier machine, centrifugal dewatering machine, drying system, storage silo, etc.

    QINGCHENYU RECYCLING Company can design different configurations of PE PP washing line according to customer final product requirements. At present, the PE PP recycling line can be provided 200kg/h up to 2000 kg/hour.

    Usage and Features:

    Waste film washing line is independently-developed by our company on the basis of European technology. It is divided into belt conveyor, metal detector, single double film shredder, film crusher with water, floating tank, hot washer,high speed friction washer, special film squeezer or film densifier machine, centrifugal dewatering machine, drying system, cyclone silo and so on.


    Our company has a new type shredder&crusher specially designed for films. The film shredder has double shaft and special blade construction, it can effectively crush the films and increase the output. The final size of the film is very suitable for the following washing line, and also save energy&labor.


    At the same time, it can be equipped with waste film baler machine, waste film cutter machine, and drum sorting system (can effectively sort the sediment and stone inside the film, protect the blade of the rear crusher without damage).


    The dryer part can also be equipped with our company latest film squeezer (used to squeeze out the inner water of the film, improve the drying in a way, save the heating electricity efficiently).


    The waste film washing line can be designed according to the customers’ materials condition and the quality requirements of finished products.

    Our waste film recycling line processing technique is very mature, high automation and output, less investment and manpower, low energy consumption, convenient operation and maintenance.

    Our PE PP recycling line has been sold all over the world. It’s very popular among all customers at home and abroad.



    Main machine advantages:

    QINGCHENYU COMPANY customized integration of film shredding, crushing and washing solutions, it can be used in different levels of contamination materials, including PE PP film, PP fiber waste, waste film package scraps, life plastic waste, waste agriculture films, industrial packaging and waste films, Recycled material can be used for sales, granulation, injection molding, extrusion and blown film and so on.

    QINGCHENYU COMPANY also provides complete PE PP PS ABS and other rigid scraps, including injection toys, daily necessities and packaging waste, bottle-shaped container waste, electrical waste, extruded pipe, lumps and others.

    1. The whole PE PP washing line is automatic controlling, compact process, high production efficiency, and nice cleanness.

    2. This PE PP recycling line can separate muds, sands, and other impurities from films and bags easily.

    3. With materials pre-treatment system such as special film cutter, film shredder, pre-washer, label processing module, highly improve quality of end product.

    4. Provide centrifugal dewatering and squeezing technology.
    Usually our standard PE PP washing line contains the following equipments, the specific configuration can also be adjusted according to customer requirement.

    PE PP Film and Bag Washing Line(Standard Configuration) Drawing:



    PE PP Film and Bag Washing Line (Standard Configuration):


    NO. Equipment Name Main Motor power(kw) Main Stainless Steel Thickness(mm) Main Electric Element Total Power Consumption(kw) Area(m2) RequiredWorkers
    1 belt conveyor 1.1-3   ABB, Siemens, Schneider, etc 68-210 240-300 2-5
    2 PE film shredder 18.5-150 10-30
    3 belt conveyor 1.1-3
    4 crusher with water 30-110 12-30
    5 high speed screw feeder with water spraying 7.5-22 3-6
    6 screw feeder 2.2-5.5 3-5
    7 pe film washing tank 6-13 2-5
    8 screw feeder 2.2-5.5 3-5
    9 pe film squeezer 22-30 10-20
    10 pe film scattering machine 1.1-2.2 3-5
    11 belt conveyor 1.1-3
    12 bulk bag
